38″ Bar Type LCD Display
38″ Bar Type LCD Display
Model KT-380HBM-I01
KoreTouch KT-380HBM-I01 38-inch bar type PCAP touch display, 1920×502 ultra-wide, IP65, VESA 715×100, DC 12V
Highlights
- Industrial-grade LCD, continuous 24/7 operation
- Durable mechanical design for harsh environments
- PCAP: wet touch & glove touch
- Optical bonding (Wacker AB adhesive) — custom option
- AR / AF / AG surface treatment; Mohs 7; brightness up to 1,500 nits optional
- Wide-temperature design, high reliability
- IP65 rated enclosure — align sealing and cable routing with your install
Typical applications
- Retail shelf-edge, grab-and-go lanes, and narrow fascia signage
- Public transportation information strips and wayfinding
- Digital menu boards, hospitality, and ultra-wide messaging bands
- Custom aspect ratios, bonding, and input options (contact sales)
Specifications
Values below match koretouch-kt-380hbm-i01-specifications.pdf (same edition as the downloadable file in Documents). *Additional custom specifications available on request.
LCD panel
| Screen size | 38″ |
|---|---|
| IP rating | IP65 |
| Active area (H × V) | 921.3 mm × 260.0 mm |
| Pixel pitch | 0.4845 mm × 0.4845 mm (52 PPI) |
| Resolution | 1920 × 502 (>3:1) |
| Display type | a-Si TFT-LCD |
| Contrast ratio | 1400:1 (typ.) |
| Color | 1.07B |
| Brightness | 1000 cd/m² |
| Backlight | LED / 30,000 h (typ.) |
| Viewing angles (CR=10, typ.) | 89° / 89° / 89° / 89° (L/R/U/D) |
| Response time (Tr+Td, typ.) | 5 ms (typ.) |
Touch screen
| Technology | Capacitive multi-touch |
|---|---|
| Interface | USB |
| Surface treatment | AG / AR / AF optional |
| Optical bonding | Yes (Wacker AB adhesive) |
| Cover glass thickness | 3 mm |
Connectors & power
| Video | HDMI + VGA + DVI (DisplayPort optional) |
|---|---|
| Power input | DC 12 V (9–36 V optional) |
| Output power | ≤ 98 W |
Operation & mechanical
| Overall dimensions (W × H × T) | 976.6 × 325.3 × 70 mm |
|---|---|
| Operating temperature | 0°C ~ 50°C |
| Storage temperature | −20°C ~ 60°C |
| Relative humidity | 10% ~ 90% RH (non-condensing) |
| Housing | Sheet metal |
| VESA mount | 715 × 100 |
| Weight | 14 kg |
| Warranty | 1 year |
Outline & drawing
Envelope and drill pattern follow the dimensional drawing: VESA 715 × 100 with 4× M6 pilot holes per drawing. Overall depth 70 mm. Confirm tolerances and cutouts on the specification PDF before tooling.
Envelope
976.6 × 325.3 × 70 mm
Active + mounting
Active: 921.3 × 260.0 mm · VESA 715 × 100 (4×M6)
Custom I/O, glass, or IP targets?
Our team develops integration concepts directly from your project requirements without the need for initial technical drawings. Share your goals for I/O, glass, IP, and certification. We translate these parameters into optimized optical stack-ups, ensuring every bonding and sealing detail is refined for reliable field deployment.
